CRYOGENIC AIR SEPARATION PLANT
FOR NITROGEN PRODUCTION
FOR NITROGEN PRODUCTION
XLA company have exported multiple skid-mounted &unattended nitrogen plants to Europe .
Advantage of this plant:
- The whole plant just includes two units: cold box and warm end skid.
- Cold box and warm end skid are completely installed in XLA factory to save the installation cost for customer.
- Standard 40 feet container size design very convenient for transportation..
- Warm end skid: the internal contains adsorption canister, compressor, instrument control system, cooling & purification system etc.
| Flow rate | 350-1000Nm3/h |
| Purity inclusive of argon | 99.999% |
| Maximum oxygen content | 3ppm |
| Dew point | <-70ºC |
| Min pressure at battery limits | 6.5-9barg |
| Temperature | 25ºC (subject to ambient temperature) |
